ELCAR EVA07B (AUTO)
With the EVA07B (AUTO) portable EV charger, you can charge your car with 7.4 kW adjustable current between 6 and 32 amps.
Power Specification
The main features of the EVA07B (AUTO) charger include high power, which allows you to charge large capacity batteries in a short time. The device has overload and short circuit protection for maximum safety when charging.
| The Maximum Output Current: | 32 A |
|---|---|
| DC Voltage Output: | 230 VDC |
| Connector type : | GBT/AC |
| Output current: | 32 A |
| Output power : | 7.4 kW |
| Power input: | 220 V |
| Phase number : | 1 Phase |
User Interface & Control
The EVA07B (AUTO) charger is easy to use with a simple and intuitive interface. You can select the desired charging mode and then simply connect the device to the battery of an electric vehicle to start charging.
| Indicators: | ✔ Yes |
|---|---|
| Display: | ✔ Yes |
Environmental
One of the main advantages of the EVA07B (AUTO) charger is its versatility. It is suitable for use with various types of electric vehicles, including hybrid and all-electric vehicles. In addition, the device has a compact size and light weight, which makes it easy to carry.
| Altitude : | 2000 m |
|---|---|
| Operating humidity : | 95 % |
| Operating temperature : | -30 +60 C |
Protection
The EVA07B (AUTO) charger comes with a 1 year warranty and provides a high level of quality and reliability. If you have any questions or problems with the device, you can always contact our customer support team to get the necessary assistance.
| Emergency Stop: | ✖ No |
|---|---|
| Ground protection : | ✔ Yes |
| Leakage protection : | ✔ Yes |
| Power line protection : | ✔ Yes |
| OverLoad protection : | ✔ Yes |
| Short circuit protection : | ✔ Yes |
| IP Code : | IP67 |
Wall box mechanical
Choosing the EVA07B (AUTO) charger, you get a reliable and high-quality device for charging your electric vehicle batteries.
| Enclosure Material : | Tempered glass, Plastic |
|---|---|
| Charging Cable Length: | 5 m |
| Weight : | 2.9 kg |
